ΘΕΡΜΙΚΟ ΡΕΛΕ LT2-E1312 5.5-8A

ΘΕΡΜΙΚΟ ΡΕΛΕ LT2-E1312 5.5-8A

Technical characteristics of LT2-E:
– Rated operating current: 0,10 up to 93А
– Rated operating voltage : up to 690V АС;50/60Hz
– Insulation voltage: >690V
– Impulse voltage withstand: 6000V
– Mechanical wear resistance (number of cycles): ≥10000000
– Electrical wear resistance (number of cycles): ≥1000000
– Ambient temperature: -10° to 65ºС
– Maximum altitude: up to 2000m

n

Advantages:
– Indication for protection activating
– Choice of protection restoration method
– Allows adjustment of the operation range
– Allows operation at higher frequency
– High reliability of the current parameters
– Increase the effectiveness and prolongs the term of operation.

n

Functions:
– For protection of induction motors from overload or overheat
– To prevent the motor from operation at unusual temperature conditions

n

Applications:
– Industry
– Building construction

n

Моunting: To the terminals of the contactor and it is additionally clamped to its frame through a pin

n

Standard: EN60947-1; EN60947-4-1; LVD; EMC
